Technical specifications | |
Air volume (l/min.) negative pressure (mbar/kPa) power Pmax (W) power Piec (W) Working noise (db(A)) Container volume (l/max) Mains connection (V/~/Hz) Dimensions L x W x H (mm) Weight (kg) Cable length (m) | 3700 250/25 1500 1200 59 30 230/1/50-60 450 x 380 x 595 10 7,5 |
SCOPE OF DELIVERY | |
Suction hose Extension tube Safety filter bag Filter element „H“ Tool adapter Floor nozzle Inclined rubber nozzle | ✓ ✓ ✓ ✓ ✘ ✓ ✓ |
Technical specifications | |
Air volume (l/min.) negative pressure (mbar/kPa) power Pmax (W) power Piec (W) Working noise (db(A)) Container volume (l/max) Mains connection (V/~/Hz) Dimensions L x W x H (mm) Weight (kg) Cable length (m) | 3700 250/25 1500 1200 59 47 230/1/50-60 450 x 380 x 750 11 7,5 |
SCOPE OF DELIVERY | |
Suction hose Extension tube Safety filter bag Filter element „H“ Tool adapter Floor nozzle Inclined rubber nozzle | ✓ ✓ ✓ ✓ ✘ ✓ ✓ |
Technical specifications | |
Manufacturer Typ Voltage Engine power Air volume max. egative pressure 2 Filter levels dust class H Dirt container Protection class Suction connection Dimension Wight | Fa. EVO Products SES-ECODust 1200 230 V 1.200 W 165 m³/h 210 mbar 1,00 m² (M), + 1,7 m² (H) 25 ltr. IP 33 ∅ 60 mm 48x48x105 mm 35 kg |
SCOPE OF DELIVERY | |
Suction hose Extension tube Safety filter bag Filter element „H“ Tool adapter Floor nozzle Inclined rubber nozzle | ✓ ✓ ✓ ✓ ✘ ✓ ✓ |
Technical specifications | |
Voltage Engine power Ait volume max. negative pressure Filter quantity „M“ Filter quantity „H“ (H14) Dirt ontainer Protection class Sound pressure level Suction connection Dimension Wight Dust class H/Asbest |
400 V 5500 Watt 480 m³/h 260/340 max. mbar 3,2 m² + 4,3 m² 100 ltr. IP 55 78 dB(A) ø 80 mm 110x68x152 cm 198 kg 251-4121 |
